Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Arch #13 Close-up of side seals. The exposed portion of the 24" steel plates imbedded 12" in the groin gunite was bent over the ends of the courses of face steel and welded.
